Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Table 78: Charge switch failure voltage (0x5121 / 0x158)
Code
®
PROFINET
code
0x5121 0x158

9.3.44 EE Checksum Error (parameter missing) (0x5530 / 0x10A)

This error is valid for PSM 510, DAM 510, ACM 510, and SDM 511/SDM 512.
Table 79: EE Checksum Error (parameter missing) (0x5530 / 0x10A)
Code
®
PROFINET
code
0x5530 0x10A

9.3.45 Parameter error (0x6320 / 0x10B)

This error is valid for PSM 510, DAM 510, ACM 510, and SDM 511/SDM 512.
Table 80: Param err (0x6320 / 0x10B)
Code
®
PROFINET code
0x6320 0x10B

9.3.46 Conf par ver (0x6382 / 0x15D)

This error is valid for PSM 510, DAM 510, ACM 510, and SDM 511/SDM 512.
Table 81: Configuration parameters version error (0x6382 / 0x15D)
Code
®
PROFINET
code
0x6382 0x15D

9.3.47 Configuration parameters limits error (0x6383 / 0x164)

This error is valid for PSM 510, DAM 510, and ACM 510.
182 | Danfoss A/S © 2019.10
Name Severity (warning/
error/trip lock)
Charge switch Trip lock
failure voltage
Name
EE Checksum Error (pa-
rameter missing)
Name Severity (warning/error/trip
lock)
Parameter error Trip lock
Name Severity (warning/
error/trip lock)
Configuration param- Trip lock
eters version error
Description
Indicates a malfunction of the in-
ternal charge circuit.
Severity (warning/ Description
error/trip lock)
Trip lock Missing parameter in internal de-
vice configuration.
Description
Configuration parameter set version mis-
match: parameter set is not valid for this
device.
Description
A parameter has an invalid value.
AQ262450196490en-000101 / 175R1170
Diagnostics
LCP name
Chg switch
fail
LCP name
config err
LCP name
param err
LCP name
conf par ver
