Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
2
1
Illustration 116: Disconnecting the I/O Shielding Plate
Unplug the top connectors [1].
Unscrew the screw on the I/O shielding plate [2].
Pull the I/O shielding plate upwards to remove it.
5. Release the securing clamp at the top of the module.
Illustration 117:
6. Tilt the module forward and remove it from the backplate.
Danfoss A/S © 2019.10
Releasing the Securing Clamp
Maintenance, Decommissioning, and
1
AQ262450196490en-000101 / 175R1170| 195
Disposal
