Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
MSD510EXM510F1C062AD6E20XXXXXXXXXXXXXXXX

3.7 Local Control Panel (LCP)

3.7.1 Overview of the Local Control Panel

The LCP is the graphical user interface for diagnostic and operating purposes. It is available as an option and can be connected to the
system modules using an optional cable (M8 to LCP SUB-D extension cable).
The LCP display provides the operator with a quick view of the state of the system modules, depending on which device it is connected
to. The display shows parameters and alarms/errors and can be used for commissioning and troubleshooting.
It can also be used to perform simple functions, for example activating and deactivating the output lines on the DAM 510 and opening
the mechanical brake on the SDM 511/512.
The LCP can be mounted on the front of the control cabinet using a mounting set (available as an accessory) and then connected to
the modules via M8 to SUB-D cables (available as an accessory). See the VLT
Design Guide for accessory order numbers.
-
Further information on the LCP functions can be found in the VLT
Programming Guide.

3.7.2 Layout of the Local Control Panel

The local control panel is divided into 4 functional groups:
•

A: Display area

• B: Display menu keys
• C: Navigation keys and indicator lights (LEDs)
• D: Operation keys and reset
To adjust the display contrast, press [Status] and the [▵]/[▿] keys.
3.7.2.1 A: Display Area
The values in the display area differ depending on which module the LCP is connected to.
The display area is activated when the module it is connected to received power from U
Danfoss A/S © 2019.10
®
Servo Drive System ISD 510, DSD 510, MSD 510
N O T I C E
®
Servo Drive System ISD 510, DSD 510, MSD 510
AUX
System Description
.
AQ262450196490en-000101 / 175R1170| 37
