Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

9.3.55 External position sensor error (0x7380 / 0x10D)

This error is valid for DAM 510 and SDM 511/SDM 512.
Table 90: External position sensor error (0x7380 / 0x10D)
Code
®
PROFINET
code
0x7380 0x10D

9.3.56 Following error (0x8611 / 0x10E)

This error is valid for SDM 511/SDM 512.
Table 91: Following error (0x8611 / 0x10E)
Code
®
PROFINET code
0x8611 0x10E

9.3.57 Homing error on entering homing mode (0x8693 / 0x10F)

This error is valid for SDM 511/SDM 512.
Table 92: Homing error on entering homing mode (0x8693 / 0x10F)
Code
®
PROFINET
code
0x8693 0x10F

9.3.58 Homing error on start homing method (0x8694 / 0x110)

This error is valid for SDM 511/SDM 512.
Table 93: Homing error on start homing method (0x8694 / 0x110)
Code
®
PROFINET
code
0x8694 0x110

9.3.59 Homing error distance (0x8695 / 0x111)

This error is valid for SDM 511/SDM 512.
Danfoss A/S © 2019.10
Name
External position sensor
error
Name Severity (warning/error/trip
lock)
Following error Warning, error
Name Severity (warning/
error/trip lock)
Homing error on enter- Warning
ing homing mode
Name Severity (warning/
error/trip lock)
Homing error on start Warning
homing method
Severity (warning/
error/trip lock)
Error
Description
Could not enter homing mode
(for example velocity not 0).
Description
Could not start homing method
(for example drive not in stand-
still).
Description
External encoder data could
not be read.
Description
A following error has occurred.
AQ262450196490en-000101 / 175R1170| 185
Diagnostics
LCP name
ext sensor err
LCP name
following err
LCP name
Homing mode
fail
LCP name
Homing meth-
od fail
