Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
6.14 Programming with SIMOTION SCOUT®
6.14.1 Requirements for Programming with SIMOTION SCOUT®
The following files are required to integrate the servo system modules into a SIMOTION SCOUT
Table 19: Required Files
System Module
Whole servo system
Servo Drive Module SDM 511/SDM 512 and
ISD 510/DSD 510 servo drive
Power Supply Module PSM 510
Decentral Access Module DAM 510
Auxiliary Capacitors Module ACM 510

6.14.2 Connecting to the PLC

Information on how to connect to the PLC can be found in detail in the SIMOTION SCOUT
Open SIMOTION SCOUT® and go to [Help → Help Topics → Getting Started with SIMOTION SCOUT → Download the project to the
target system → Connect to selected target devices → Go online].
6.14.3 Creating a SIMOTION SCOUT® Project
Information on how to install SIMOTION SCOUT®
SIMATIC STEP 7 V5.5 or higher with HF11 must be installed to create a project.
-
Information on how to create a project in SIMOTION SCOUT
®
SIMOTION SCOUT and go to [Help → Help Topics → Getting started with SIMOTION SCOUT → Create SIMOTION device and configure
PG/PC communication connection].
Danfoss A/S © 2019.10
File required
Package of libraries for the MSD 510 servo system: Danfoss_VLT_ServoMo-
tion_V_x_y_z.zip
Online Help file(.chm): Programming with SIMOTION SCOUT
GSDML file (General station description):
GSDML-V2.31-Danfoss-DDS-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.31-Danfoss-PSM-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.31-Danfoss-DAM-yyyymmdd.xml
GSDML file (General station description):
GSDML-V2.31-Danfoss-ACM-yyyymmdd.xml
®
can be found in detail in the SIMOTION SCOUT
N O T I C E
®
can be found in detail in the SIMOTION SCOUT
Commissioning
®
project:
®
®
Help.
®
Configuration Manual.
®
online help. Open
AQ262450196490en-000101 / 175R1170| 113
