Commissioning
Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

6.14.9.2 Configuring the Update Time

Procedure
1. Open the HW Config tool.
®
2. Select the path for the PROFINET
I/O system.
3. Select the menu [Edit → Object properties].
4. In the next window, open the Update Time tab, highlight the I/O device and click on the Edit button.
5. In the next window (Edit Update Time/Mode), select the Update Time and click on OK.
Illustration 95: Set Update Time
N O T I C E
®
The system cycle clocks of the PLC program must be the same as the PROFINET send clock, otherwise data may be
-
lost and performance reduced.

6.14.10 Accessing Inputs and Outputs

Context:
®
SIMOTION SCOUT provides access to the device inputs and outputs of the SIMOTION device via the process image of cyclic tasks using
I/O variables.
