11.4 Decentral Access Module (DAM 510)

11.4.1 Dimensions of DAM 510

84.3
[3.32]
13 50 21.3
[0.51] [1.97] [0.84]
STATUS DAM
DEV
SVS ST
NET ST
AUX
LINK/ACT
X1
X2
X3
LCP
Illustration 128: Dimensions of DAM 510
11.4.2 Characteristic Data for DAM 510
Table 125: Characteristic Data for Decentral Access Module (DAM 510)
Definition
Input
DC-link
DC-link capacitance
Maximum input current
U
AUX
U current consumption at 24 V DC
AUX
U current consumption at 48 V DC
AUX
210 | Danfoss A/S © 2019.10
270
[10.63]
Unit Power size 1
V DC
µF
A DC 15
V DC
A DC
A DC
25 25
[0.98] [0.98]
Ø5.2
[0.2]
Ø5.2
[0.2]
Power size 2
565–680 ±10%
660
25
24/48 ±10%
0.5
0.3
AQ262450196490en-000101 / 175R1170
Specifications
