Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
60
[2.36]
101
[3.98]
Illustration 31: Minimum Space Required at the Sides

4.7.2 Installation Aids and Tools Required

For installation of the MSD 510 system modules, the tools corresponding to the fixings screws (not included) are required.

4.7.3 Fitting Instructions for System Modules

Context:
Mount the MSD 510system component with the highest output power next to the PSM 510. Mount the remaining system
-
components in descending order of output power.
52 | Danfoss A/S © 2019.10
60
[2.36]
106
[4.17]
N O T I C E
Mechanical Installation
AQ262450196490en-000101 / 175R1170
