6.16 VLT® Servo Toolbox Software

6.16.1 Overview

®
The VLT
Servo Toolbox is a standalone PC software designed by Danfoss. It is used for parameterization and diagnostics of the system
modules. It is also possible to operate the devices in a non-productive environment.
®
The VLT
Servo Toolbox contains several subtools, which provide various functionalities.
Table 20: Important Subtools
Subtool
Scope
Parameter list
Firmware update
Drive control
PSM control
DAM control
ACM control
CAM editor
Configuration parameter
Drive commissioning
The detailed description of the VLT
System ISD 510, DSD 510, MSD 510 Programming Guide.

6.16.2 System Requirements

®
To install the VLT
Servo Toolbox software, the PC must meet the following requirements:
Supported hardware platforms: 32.bit, 64-bit.
Supported operating systems: Windows 7, Windows 8.1, Windows 10.
.NET framework version: 4.7.
Minimum hardware requirements: 512 MB RAM, Intel Pentium 4 with 2.6 GHz or equivalent, 20 MB hard disk space.
Recommended hardware requirements: Minimum 1 GB RAM, Intel Core i5/i7 or compatible.
6.16.3 Installing the VLT® Servo Toolbox Software
Context:
Administrator rights are required to install the software with the Windows operating system. If necessary, contact your system
administrator.
134 | Danfoss A/S © 2019.10
Description
For visualization of the tracing functionality of the servo drives, the Power Supply Module (PSM 510),
the Decentral Access Module (DAM 510), and the Auxiliary Capacitors Module (ACM 510).
For reading/writing parameters.
For updating the firmware on the devices.
For operating the servo drives for testing purposes.
For operating the Power Supply Module (PSM 510) for testing purposes.
For operating the Decentral Access Module (DAM 510) for testing purposes.
For operating the Auxiliary Capacitors Module (ACM 510) for testing purposes.
For designing CAM profiles for the servo drives.
For setting up the motor and feedback parameters, and PID settings.
For motor feedback adjustment and inertia measurement.
®
Servo Toolbox functionality and the full parameter lists can be found in the VLT
Commissioning
®
Servo Drive
AQ262450196490en-000101 / 175R1170
