11.5 Auxiliary Capacitors Module (ACM 510)

11.5.1 Dimensions

84.3
[3.32]
13 50 21.3
[0.51] [1.97] [0.84]
Illustration 129: Dimensions of ACM 510

11.5.2 Characteristic Data for ACM 510

Table 126: Auxiliary Capacitors Module (ACM 510) Characteristic Data
Definition
DC-link
DC-link capacitance
U
AUX
U current consumption at 24 V DC
AUX
U current consumption at 48 V DC
AUX
Cooling
Mounting
Weight
Dimensions (W x H x D)
212 | Danfoss A/S © 2019.10
270
[10.63]
Unit Value
V DC 565–680 ±10%
µF 2750
V DC 24/48 ±10%
A DC 0.5
A DC 0.3
– Natural convection
– Wall-mounted on backplate using backlink connector
kg 3.54
mm 84 x 371 x 270
Specifications
25 25
[0.98] [0.98]
Ø5.2
[0.2]
Ø5.2
[0.2]
