3 System Description
3.1 Overview of the VLT® Multiaxis Servo Drive System MSD 510
®
The VLT Multiaxis Servo Drive System MSD 510 is a high-performance central servo motion solution. The open system supports the
® ® ®
real-time Ethernet protocols EtherCAT , Ethernet POWERLINK , and PROFINET .
PSM
SDM 511
FS2
SDM 511
FS1
EXM 510
SDM 512
FS1
DAM 510
ACM 510
Illustration 3: MSD Modules
The system comprises:
