Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

3.3.4.1 Connectors on the Top of SDM 511

1 2 3 4
7 6
1 External encoder connector
3 Ethernet connector OUT
5 STO connector IN
7 Relay connector
Illustration 9: SDM 511, Enclosure Size 1 (FS1)
1 2 3
7 6
1 External encoder connector
3 Ethernet connector OUT
5 STO connector IN
7 Relay connector
Illustration 10: SDM 511, Enclosure Size 2 (FS2)

3.3.4.2 Connectors on the Bottom of SDM 511

1 Motor feedback connector
30 | Danfoss A/S © 2019.10
5
4
5
1
3
2 Ethernet connector IN
4 I/O connector
6 STO connector OUT
2 Ethernet connector IN
4 I/O connector
6 STO connector OUT
2
2 Motor brake and thermistor connector
System Description
AQ262450196490en-000101 / 175R1170
