Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Procedure
1. Open the HW Config tool.
2. Select the path for the PROFINET
3. Select the menu [Edit → PROFINET IO → Topology].
4. In the next window, select the Graphic view tab.
Illustration 93:
®
5. Connect the PROFINET
drawing a line between the 2 ports.
6. Once all connections are made, click on OK.
Danfoss A/S © 2019.10
®
I/O system or PROFINET
Graphic View Tab in Topology Editor
device with the station. Establish connections between ports by holding down the left mouse button and
®
module, for example a Danfoss MSD 510 series.
Commissioning
AQ262450196490en-000101 / 175R1170| 125
