Danfoss VLT MSD 510 Operating Manual page 199

Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Procedure
1. Remove the screws [1] and remove the cover.
Illustration 119:
2. Use a screwdriver to remove the fuses and replace them with the same number of identical type fuses (see
Illustration 120:
3. Replace the cover and tighten the screws [1]. The tightening torque is 2 Nm.
Danfoss A/S © 2019.10
1
Opening the Cover on DAM 510
Removing the Fuse
Maintenance, Decommissioning, and
5.4.1 Fuses).
AQ262450196490en-000101 / 175R1170| 199
Disposal
