Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
1
2
STATUS ACM
DEV
CAP ST
NET ST
LINK/ACT
X1
X2
3
LCP
4
1 Connectors: I/O, relay, and Ethernet
3 LCP connector
Illustration 18:
ACM 510
3.5.2 Connectors on the Top of ACM 510
1
2
4
3
1 Ethernet connector IN
3 I/O connector
Illustration 19:
Connectors on the Top of ACM 510
Danfoss A/S © 2019.10
2 Operating LEDs
4 PE screw
2 Ethernet connector OUT
4 Relay connector
AQ262450196490en-000101 / 175R1170| 35
System Description
