Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

3.9.2 Wiring of Output Filter

U U1
V V1
W1
W
PE
PE
Illustration 24: Wiring Diagram of Output Filter

3.9.3 Standard Cabling Concept for 2 Decentral Access Modules (DAM 510)

In this example, a hybrid feed-in cable with quick-release connectors provides the supply voltage from the DAM 510 to the 1st ISD 510/
DSD 510 servo drive.
PLC
24/48 V
STO
STATUS PSM STATUS DAM STATUS DAM
DEV
DEV DEV
STO
STO STO
NET ST
NET ST NET ST
AUX AUX
LINK/ACT
LINK/ACT LINK/ACT
X1 X1 X1
X2
X2 X2
X3 X3
PSM DAM DAM
510 510 510
3
AC 400–480 V
UDC + Real-Time Ethernet Bus + STO + U AUX
1 Hybrid feed-in cable
3 AC choke
Illustration 25: Standard Cabling Concept for 2 Decentral Access Modules (DAM 510)

3.10 Software

The software for the servo system comprises:
44 | Danfoss A/S © 2019.10
U2
U
V2
V M
W 3
W2
PE
PE
Status Quick Main Alarm
Menu Menu Log
OK
Hand Off Auto Reset
On On
LCP
UDC + Real-Time Ethernet Bus + STO + U AUX
1
ISD 510
DSD 510
2
. . .
2 Hybrid loop cable
System Description
. . .
AQ262450196490en-000101 / 175R1170
