User Interface

4.1.2 Setting LCP Display Values

The display area is activated when the adjustable
frequency drive receives power from AC line voltage, a DC
bus terminal, or an external 24 V DC supply.
The information displayed on the LCP can be customized
for user application.
•
Each display readout has a parameter associated
4 4
with it
•
Options are selected in the quick menu Q3-13
Display Settings
•
Display 2 has an alternate larger display option
•
The adjustable frequency drive status at the
bottom line of the display is generated automat-
ically and is not selectable
Figure 4.2 Display Readouts
Figure 4.3 Display Readouts
Display
1.1
1.2
1.3
2
3
Table 4.1 Legend to Figure 4.2 and Figure 4.3
4-2
Status
799 RPM 7.83 A
1.1
0.000
1.2
53.2%
Auto Remote Ramping
2
3 1.3
Status
207RPM 5.25A
1.1
6.9Hz
Auto Remote Running
Parameter number Default setting
0-20 Motor RPMs
0-21 Motor current
0-22 Motor power (kW)
0-23 Motor frequency
0-24 Reference in percent
MG20M922 - VLT
®
VLT AQUA Drive
Instruction Manual

4.1.3 Display Menu Keys

Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Status
Figure 4.4 Menu Keys
Key
Status
1 (1)
36.4 kW
Quick Menu
1 (1)
24.4 kW
Main Menu
1.3
1.2
2
Alarm Log
Table 4.2 Function Description Menu Keys
®
is a registered Danfoss trademark
Quick Main
Menu Menu
Function
Shows operational information.
•
In Auto mode, press to toggle between
status readout displays.
•
Press repeatedly to scroll through each
status display.
•
▲ ▼
Press [Status] plus [ ] or [ ] to adjust the
display brightness.
•
The symbol in the upper right corner of the
display shows the direction of motor
rotation and which set-up is active. This is
not programmable.
Allows access to programming parameters for
initial set-up instructions and many detailed
application instructions.
•
Press to access Q2 Quick Set-up for
sequenced instructions to program the basic
adjustable frequency drive set-up
•
Follow the sequence of parameters as
presented for the function set-up
Allows access to all programming parameters.
•
Press twice to access top-level index
•
Press once to return to the last location
accessed.
•
Press to enter a parameter number for
direct access to that parameter.
Displays a list of current warnings, the last ten
alarms, and the maintenance log.
•
For details about the adjustable frequency
drive before it entered the alarm mode,
select the alarm number using the
navigation keys and press [OK].
Alarm
Log
