1.7 Terminology

Table 3: Terminology
Term
ACM 510
DAM 510
DSD 510
DSD 510 system compo-
nents
EXM 510
Feed-in cable
ISD 510
ISD 510 system components
LCP
Loop cable
MSD 510
MSD 510 system compo-
nents
PLC
PSM 510
SDM 511
SDM 512
System modules
V PSM
IN
V PSM
OUT
Danfoss A/S © 2019.10
Description
Auxiliary Capacitors Module
Decentral Access Module that connects the Danfoss decentral servo drives (ISD 510 and DSD 510) to
the servo system via a hybrid cable.
Decentral Servo Drive
Includes DSD 510 servo drives, PSM 510, DAM 510, and the optional ACM 510.
Extension module
Hybrid cable for connection from the DAM 510 to the 1st servo drive.
Integrated Servo Drive
Includes ISD 510 servo drives, PSM 510, DAM 510, and the optional ACM 510.
Local Control Panel
Hybrid cable for connecting servo drives in daisy-chain format.
Multiaxis Servo Drive
Includes SDM 511/SDM 512, PSM 510, DAM 510, and the optional ACM 510.
Programmable Logic Controller (external device for controlling the servo system).
Power Supply Module that generates a 565–680 V DC supply.
Servo Drive Module (single axis)
Servo Drive Module (double axis)
Includes PSM 510, DAM 510, and the optional ACM 510.
Input of PSM 510 (V AC).
Output of PSM 510 (V DC).
