The IP address assignment is also required when using indirect communication via the VLT
Servo Drive System ISD 510, DSD 510, MSD 510 Programming Guide for further information).
The IP address and the device name can also be assigned using PRONETA, a free tool that supports in the analysis and configuration of
®
PROFINET networks.

6.7 Power-Up Time

The maximum power-up time for the system components is 15 s. This means the time from supplying the system with auxiliary voltage
to the module being initialized completely.
The power-up time stated is an indicative time. The exact status of the module can be seen via the statusword.
Do not operate any of the system modules until they are all powered up correctly.
-
If 2 PSM 510 modules are mounted in parallel, power up both PSM 510 modules simultaneously (within a maximum delay
-
of 1 second).

6.8 System Module Charging Time

The charging time of the system is determined by the longest charging time of each individual system module.
The exact status of each module can be seen via the statusword.
Do not operate any of the system modules until they are charged up completely and are in state Operation enabled.
-
Table 16: DC-Link (UDC) Charging Time for PSM 510, DAM 510, and ACM 510
Specification
UDC charging time
Table 17: DC-Link (UDC) Charging Time for SDM 511
Specification
UDC charging time
Danfoss A/S © 2019.10
N O T I C E
N O T I C E
Unit PSM 510
s 2.0
Unit SDM 511
2.5 A
s
®
Servo Toolbox software (see the VLT
DAM 510
2.0
SDM 511 SDM 511
5 A 10 A
2.0
AQ262450196490en-000101 / 175R1170| 85
Commissioning
®
ACM 510
3.5
SDM 511
20 A
