Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
• Flow wrapping
• Bag maker
• Tray sealing
• Shrink wrapping
Industrial and pharmaceutical packaging machines:
• Palletization
• Top loader
• Cartoning
• Tube filling
• Blister machine
• Liquid filling
• Solid dosing

3.1.2 Maximum Number of Modules

The maximum number of modules in the MSD 510 system is:
• PSM 510: 2 per system
• DAM 510: 3 per system (Depending on the system architecture it may be possible to add more. Contact Danfoss for further
information.)
• SDM 511/SDM 512: Depends on the current rating and output power of the servo drive modules and the AUX current consumption
during operation. Contact Danfoss for further information.

3.2 Power Supply Module PSM 510

3.2.1 Overview

PSM is the abbreviation for Power Supply Module. It is the power supply to the servo system. The PSM 510 supplies a DC power voltage
and guarantees high-density output. The DC-link and 24/48 V DC are distributed via the backlink in the backplates to all system
modules. The PSM 510 can be controlled via Ethernet-based fieldbus.
LEDs on the front of the PSM 510 show the operating status and warnings.
The MSD 510 system is designed for use within a control cabinet. If the STO function is used, the cabinet must be rated at
-
least IP54.
The PSM 510 has a protection rating of IP20 according to IEC/EN 60529 (except connectors, which are IP00).
-
The PSM 510 may be damaged if exposed to fluids.
-
All power cables are wired into the PSM 510, therefore at least 1 PSM 510 is required for each system.
The PSM 510 also performs service functions, such as voltage measuring, and is cooled by an internal fan.
The PSM 510 is available in 3 power sizes and delivers an output power of 10 kW, 20 kW, or 30 kW with 200% overload capacity for 3
seconds. Two PSM 510 modules can be used in parallel to achieve an output power of up to 60 kW.
Danfoss A/S © 2019.10
N O T I C E
System Description
AQ262450196490en-000101 / 175R1170| 25
