Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

5.8.2 Connecting the Brake/Thermistor Cable

Context:
1 Motor temperature –
3 Motor brake –
Illustration 44:
Brake/Thermistor Cable
5
1 Motor PE screw
3 Cable tie for brake/thermistor cable
5 EMC plate screw
Illustration 45:
Connecting the Brake/Thermistor Cable
Use a motor with reinforced insulation between the thermistor and the motor windings (tested with 4300 V DC and
-
8000 V
impulse).
peak
66 | Danfoss A/S © 2019.10
55
8
1
2
3
4
2 Motor temperature +
4 Motor brake +
1
2
3
2 Brake/thermistor connector
4 EMC plate
N O T I C E
Electrical Installation
AQ262450196490en-000101 / 175R1170
