Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Only PELV potential can be connected to the STO inputs.
-

11.7.10.3 STO Connectors on the DAM 510

11.7.10.3.1 STO Connectors on the Top of DAM 510
There is 1 input and 1 output STO connector on the top of the Decentral Access Module (DAM 510).
1 2
Illustration 147: STO Output Connector on the Top of DAM 510
3 4
Illustration 148: STO Input Connector on the Top of DAM 510
230 | Danfoss A/S © 2019.10
N O T I C E
Specifications
AQ262450196490en-000101 / 175R1170
