Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Table 50: Output power trip (0x2397 / 0x12B)
Code
®
PROFINET code
0x2397 0x12B

9.3.16 I2T overload motor (0x239B / 0x102)

This error is valid for SDM 511/SDM 512.
Table 51: Short circuit (0x239B / 0x102)
Code
®
PROFINET code
0x239B 0x102

9.3.17 Mains phase loss (0x3130 / 0x12F)

This error is valid for PSM 510.
Table 52: Mains phase loss (0x3130 / 0x12F)
Code PROFINET™
code
0x3130 0x12F

9.3.18 DC link overvoltage (0x3210 / 0x103)

This error is valid for PSM 510, DAM 510, and ACM 510.
Table 53: DC link overvoltage (0x3210 / 0x103)
Code
®
PROFINET code
0x3210 0x103

9.3.19 Overcurrent trip SW (0x3210 / 0x103)

This error is valid for SDM 511/SDM 512.
Danfoss A/S © 2019.10
Name Severity (warning/error/
trip lock)
Output power Error
trip
Name Severity (warning/error/trip
lock)
2 Warning, error
I T overload motor
Name Severity (warning/
error/trip lock)
Mains Error
phase loss
Name Severity (warning/error/trip
lock)
DC link overvolt- Error
age
Description
The peak output power of the de-
vice is exceeded.
Description
2
I T overload motor error.
Description
Mains phase loss detected.
This occurs when a phase on mains is missing,
or when the mains is imbalanced.
Description
DC-link voltage exceeds lim-
it.
AQ262450196490en-000101 / 175R1170| 175
Diagnostics
LCP name
Out pow
LCP name
IIT ovld motor
LCP name
phase loss
LCP name
UDC overvolt
