Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
The motor temperature measurement can either be connected to the motor feedback connector or the brake and motor
-
temperature sensor connector on the servo drive module SDM 511/SDM 512 (see
Sensor Connector on SDM 511/SDM
Only PELV potential can be connected to the motor feedback connector.
-

11.7.14 External Encoder Connectors

This connector is used to connect an external encoder to SDM 511/SDM 512 and DAM 510. It provides a guide value for CAM mode and
Gear mode.
The external encoder connectors are located on the Servo Drive Modules (SDM 511/SDM 512) and the Decentral Access Module
(DAM 510) as follows:
• SDM 511: E SDM1
• SDM 512: E SDM1 and E SDM2
• DAM 510: E DAM
5
9 6
Illustration 153: External Encoder Connector
Table 154: External Encoder Connectors
Connector Description
name
E SDM1/ Used to connect the exter-
E SDM2/ nal encoder to SDM 511/
E DAM SDM 512/DAM 510.
Danfoss A/S © 2019.10
512). The connectors cannot be connected in parallel.
1
Pins
See table
155.
N O T I C E
N O T I C E
Ratings/Notes
Nominal voltage: 24 V DC, isolated (see
Nominal current: Depends on the number of servo drives in the appli-
cation.
Maximum current: 150 mA (see
Fulfill the following specifications:
• BISS/SSI
11.7.2.2 Brake and Motor Temperature
table 155)
table 155)
AQ262450196490en-000101 / 175R1170| 235
Specifications
