4 Mechanical Installation

4.1 Items Supplied

Depending on the application, the items supplied for the MSD 510 system are:
®
• VLT Power Supply Module (PSM 510)
®
• VLT Single axis Servo Drive Module (SDM 511)
®
• VLT Double axis Servo Drive Module (SDM 512)
®
• VLT Decentral Access Module (DAM 510)
®
• VLT Auxiliary Capacitors Module (ACM 510)
®
• VLT Expansion Module (EXM 510)
• AC choke
• This operating guide
• Feed-in (hybrid) cable
• Loop (hybrid) cable
The hybrid feed-in and loop cables are required when ISD510/DSD510 servo drives are used in the servo system.
-
The packaging unit depends on the number of modules delivered. Save the packaging for use in the event of product return.

4.2 Transport

• Always use means of transport and lifting gear with sufficient load capacity to transport the servo system components.
• Avoid vibration during transport.
• Avoid heavy impacts and blows.

4.3 Inspection on Receipt

Procedure
1. After receiving the delivery, immediately check whether the items supplied match the shipping documents. Danfoss does not
honor claims for faults registered later.
2. Register a complaint immediately with the carrier if there is visible transport damage.
3. Register a complaint immediately with the responsible Danfoss representative if there are visible defects or the delivery is
incomplete.

4.4 Safety Measures during Installation

Always observe the safety instructions in this manual during installation. Pay particular attention to ensuring that the following points
are always observed:
