Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
3 V
5 PE
Illustration 41: Motor Cable for 100 mm Wide Servo Drive Modules
2
Illustration 42: Connecting the Motor Cable on 50 mm Wide Servo Drive Modules
Illustration 43: Connecting the Motor Cable on 100 mm Wide Servo Drive Modules
Procedure
1. Insert the wires into the motor connector.
2. Insert the motor connector [1].
3. Secure and shield the motor cable using the cable tie [2].
Danfoss A/S © 2019.10
1
1
2
4 W
AQ262450196490en-000101 / 175R1170| 65
Electrical Installation
