Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

3.3.5.2 Connectors on the Bottom of SDM 512

1 Motor feedback connector SDM2
3 Motor brake and thermistor connector SDM1
5 Motor brake and thermistor connector SDM2
Illustration 14: SDM 512, Enclosure Size 1 (FS1)

3.4 Decentral Access Module DAM 510

3.4.1 Overview

DAM is the abbreviation for Decentral Access Module. The DAM 510 is a central interface/gateway to the decentral servo system. It is
used to connect the Danfoss VLT
hybrid feed-in cable.
The DAM 510 supplies the decentral servo drives with DC-link, U
The DAM 510 provides functions, such as:
• Overcurrent protection of the hybrid cable
• Overvoltage protection
• Charging circuit of the DC-link
• External encoder connection
• DC-link capacitance buffer for the decentral servo drives
The DAM 510 can be controlled via Ethernet-based fieldbus.
LEDs on the front of the DAM 510 show the operating status and warnings.
The MSD 510 system is designed for use within a control cabinet. If the STO function is used, the cabinet must be rated at
-
least IP54.
The DAM 510 has a protection rating of IP20 according to IEC/EN 60529 (except connectors, which are IP00).
-
The DAM 510 can be damaged if exposed to fluids.
-
An example type code for the DAM 510 is: MSD510DAM510F1C015AD6E20PLSXXXXXXXXXXXXX.
32 | Danfoss A/S © 2019.10
1 2
6 5 4 3
®
Integrated Servo Drives ISD 510 and VLT
2 Motor feedback connector SDM1
4 Motor connector SDM1
6 Motor connector SDM2
®
Decentral Servo Drives DSD 510 to the servo system via a
, STO, and the Ethernet-based fieldbus via the hybrid feed-in cable.
AUX
N O T I C E
System Description
AQ262450196490en-000101 / 175R1170
