Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System

9.3.11 AUX user limit current (0x2393 / 0x127)

This error is valid for DAM 510.
Table 46: AUX user limit current (0x2393 / 0x127)
Code
®
PROFINET
code
0x2393 0x127

9.3.12 AUX user limit current warning (0x2394 / 0x128)

This error is valid for PSM 510 and DAM 510.
Table 47: AUX user limit current warning (0x2394 / 0x128)
Code
®
PROFINET
code
0x2394 0x128

9.3.13 AUX fuse failure (0x2395 / 0x129)

This error is valid for DAM 510.
Table 48: AUX fuse failure (0x2395 / 0x129)
Code
®
PROFINET
code
0x2395 0x129

9.3.14 DC overcurrent trip (0x2396 / 0x15C)

This error is valid for DAM 510 and SDM 511/SDM 512.
Table 49: DC overcurrent trip (0x2396 / 0x15C)
Code
®
PROFINET code
0x2396 0x15C

9.3.15 Output power trip (0x2397 / 0x12B)

This error is valid for PSM 510.
174 | Danfoss A/S © 2019.10
Name Severity (warning/
error/trip lock)
AUX user limit Error
current
Name Severity (warning/
error/trip lock)
AUX user limit cur- Warning
rent warning
Name Severity (warning/
error/trip lock)
AUX fuse fail- Error
ure
Name Severity (warning/error/trip lock)
DC Overcurrent trip Error
Description
Current on the AUX line has reached
the user-defined limit for fault.
Description
Current on the AUX line has reached
the user-defined limit for warning.
Description
Fuse failure. Current or voltage is above
the limit on the AUX line.
Description
DC overcurrent trip.
AQ262450196490en-000101 / 175R1170
Diagnostics
LCP name
AUX curr limit
LCP name
AUX curr
warn
LCP name
AUX fuse fail
LCP name
overcurr trip
