Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Table 62: UDC high voltage (0x3295 / 0x136)
Code
®
PROFINET
code
0x3295 0x136

9.3.28 UDC low voltage (0x3296 / 0x137)

This error is valid for PSM 510, DAM 510, and ACM 510.
Table 63: UDC low voltage (0x3296 / 0x137)
Code
®
PROFINET
code
0x3296 0x137

9.3.29 UAUX charging error (0x3297 / 0x154)

This error is valid for DAM 510.
Table 64: UAUX charging error (0x3297 / 0x154)
Code
®
PROFINET
code
0x3297 0x154

9.3.30 UDC shutdown error (0x3298 / 0x165)

This error is valid for DAM 510.
Table 65: UDC shutdown error (0x3298 / 0x165)
Code ®
PROFINET code
0x3298 0x165

9.3.31 UAUX shutdown error (0x3299 / 0x155)

This error is valid for DAM 510.
178 | Danfoss A/S © 2019.10
Name Severity (warning/
error/trip lock)
UDC high Warning
voltage
Name Severity (warning/
error/trip lock)
UDC low volt- Warning
age
Name Severity (warning/
error/trip lock)
U charging Error
AUX
error
Name Severity (warning/error/
trip lock)
UDC shutdown Error
error
Description
The DC-link voltage is higher than the
high-voltage warning limit.
Description
The DC-link voltage is lower than the
low-voltage warning limit.
Description
Load error when U is charging. The maxi-
AUX
mum time limit to charge the AUX line has
been exceeded.
Description
Error when UDC is in shut-
down phase.
AQ262450196490en-000101 / 175R1170
Diagnostics
LCP name
UDC high volt
LCP name
UDC low volt
LCP name
UAUX charg
err
LCP name
UDC shutdwn err
