11.3.2 Motor Overtemperature Protection

The internal motor overload protection implemented in SDM 511/SDM 512 does not have thermal memory retention or speed
sensitivity.
Internal motor overtemperature protection is not incorporated, so motor overtemperature sensing is required. SDM 511/
-
SDM 512 has an input for motor temperature sensor.

11.3.3 Dimensions

84.3
[3.32]
13 50 21.3
[0.51] [1.97] [0.84]
STATUS SDM1
DEV
SVS ST
NET ST
LINK/ACT
X1
X2
LCP
STATUS SDM2
DEV
SVS ST
NET ST
LINK/ACT
X1
X2
LCP
Illustration 126: Dimensions of SDM 511/SDM 512, Enclosure Size 1 (FS1)
