Mechanical Installation
Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Illustration 33:
Mounting the Backplates in the Control Cabinet
4. Slide the module onto the carrier at the bottom of the backplate.
5. Press the 1st module onto the backlink connector at the top of the backplate.
54 | Danfoss A/S © 2019.10
AQ262450196490en-000101 / 175R1170
