Operating Guide | VLT® Multiaxis Servo Drive MSD 510 System
Table 86: Brake resistor maximum power limit (0x7181 / 0x142)
Code
®
PROFINET
code
0x7181 0x142

9.3.52 Brake resistor user power limit (0x7182 / 0x143)

This error is valid for PSM 510.
Table 87: Brake resistor user power limit (0x7182 / 0x143)
Code PROFI‐ Name
®
NET
code
0x7182 0x143 Brake resis-
tor user
power limit

9.3.53 Brake mains voltage too high (0x7183 / 0x159)

This error is valid for PSM 510.
Table 88: Brake mains voltage too high (0x7183 / 0x159)
Code
®
PROFINET
code
0x7183 0x159

9.3.54 Internal position sensor error (0x7320 / 0x10C)

This error is valid for SDM 511/SDM 512.
Table 89: Internal position sensor error (0x7320 / 0x10C)
Code
®
PROFINET
code
0x7320 0x10C
184 | Danfoss A/S © 2019.10
Name Severity (warning/
error/trip lock)
Brake resistor maxi- Warning, error
mum power limit
Severity Description
(warning/
error/trip
lock)
Warning, er- The brake resistor power limit is exceeded.
ror
The power transmitted to the brake resistor is calculated as an
average value over the last 300 s of run time.
-The calculation is based on the DC-link voltage and the brake
resistor value set in parameter 2-16 (Brake resistor power 300 s).
The error is reported when the value is exceeded within 300 s.
Name Severity (warning/error/
trip lock)
Brake mains volt- Warning
age too high
Name
Internal position sensor
error
Description
The brake resistor maximum
power limit is exceeded.
Description
The brake resistor mains volt-
age is too high.
Severity (warning/
error/trip lock)
Trip lock
Description
Absolute position sensor er-
ror.
AQ262450196490en-000101 / 175R1170
Diagnostics
LCP name
brake pwr
lim
LCP
name
brake usr
pwr lim
LCP name
brake volt
high
LCP name
int sensor err
