How to Program

2.1.6 Quick Menu Key Functions

2 2
Press [Quick Menu] to enter a list of different areas
contained in the Quick Menu.
Select Q1 My Personal Menu to show the selected personal
parameters. These parameters are selected in
parameter 0-25 My Personal Menu. Up to 50 different
parameters can be added in this menu.
Illustration 2.13 Quick Menus
Select Q2 Quick Setup to go through a selection of
parameters to get the motor running almost optimally. The
default settings for the other parameters consider the
required control functions and the configuration of signal
inputs/outputs (control terminals).
The parameter selection is effected with the navigation
keys. The parameters in Table 2.2 are accessible.
Parameter
Parameter 0-01 LanguageParameter 0-01 L
anguage
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 5-12 Terminal 27 Digital Input
Parameter 1-29 Automatic Motor
Adaptation (AMA)
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-41 Ramp 1 Ramp up Time
Parameter 3-42 Ramp 1 Ramp Down Time
Parameter 3-13 Reference Site
Table 2.2 Selection of Parameter
1) If terminal 27 is set to [0] No function, no connection to +24 V on
terminal 27 is necessary.
16
VLT
0RPM 0.00A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q4 Smart Setup
Q5 Changes Made
Setting
[kW]
[V]
[Hz]
[A]
[RPM]
[0] No function
[1] Enable complete
AMA
[RPM]
[RPM]
[s]
[s]
Danfoss A/S © 01/2018 All rights reserved.
®
AutomationDrive FC 301/302
Select Changes made to get information about:
•
The last 10 changes. Use the [
keys to scroll between the last 10 changed
parameters.
•
The changes made since default setting.
Select Loggings to get information about the show line
readouts. The information is shown as graphs.
Only parameters selected in parameter 0-20 Display Line 1.1
Small and parameter 0-24 Display Line 3 Large can be
viewed. It is possible to store up to 120 samples in the
1(1)
memory for later reference.
1)
▲ ▼
] [ ] navigation
