Parameter Descriptions
8-13 Configurable Status Word STW
This is an array parameter with 16 elements, 1 element for each
bit in range 0–15. Elements 5 and 11–15 are configurable. Each
of the bits can be configured to any of the following options.
Option:
3 3
[0] No function
[1] Profile Default
*
[2] Alarm 68 Only
[3] Trip excl Alarm 68
[4] Position Error
[5] Position Limit
[6] Touch on Target
[7] Touch Activated
[10] T18 DI status
[11] T19 DI status
[12] T27 DI status
[13] T29 DI status
[14] T32 DI status
[15] T33 DI status
[16] T37 DI status
[21] Thermal warning
[30] Brake fault (IGBT)
[40] Out of ref range
[41] Load throttle active
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
134
®
VLT AutomationDrive FC 301/302
Function:
The input is always low.
Depending on the profile set in
parameter 8-10 Control Profile.
The input goes high whenever
alarm 68, Safe Torque Off activated is
active and goes low whenever
alarm 68, Safe Torque Off activated is
not active.
NOTICE
This option is available only
with software version 48.XX.
The position error exceeds the value
of parameter 4-71 Maximum Position
Error during the time in
parameter 4-72 Position Error
Timeout.
NOTICE
This option is available only
with software version 48.XX.
A position limit is reached.
NOTICE
This option is available only
with software version 48.XX.
Target position reached in touch
position mode.
NOTICE
This option is available only
with software version 48.XX.
Touch position mode is active.
The input goes high whenever
terminal 37 has 0 V and goes low
whenever terminal 37 has 24 V.
Danfoss A/S © 01/2018 All rights reserved.
8-13 Configurable Status Word STW
This is an array parameter with 16 elements, 1 element for each
bit in range 0–15. Elements 5 and 11–15 are configurable. Each
of the bits can be configured to any of the following options.
Option: Function:
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL digital out A
[81] SL digital out B
[82] SL digital out C
[83] SL digital out D
[84] SL digital out E
[85] SL digital out F
[86] ATEX ETR cur. alarm
[87] ATEX ETR freq. alarm
[88] ATEX ETR cur.
warning
[89] ATEX ETR freq.
warning
[90] Safe Function active
[91] Safe Opt. Reset req.
See parameter group 5-3* Digital
[92] IGBT-cooling
Outputs.
[231] In Power Lim. Mot. See parameter group 4-8* Power
Limit. Use this option in motor
mode only.
[232] In Power Lim. Gen. See parameter group 4-8* Power
Limit. Use this option in generating
mode only.
[233] In Power Limit See parameter group 4-8* Power
Limit. Use this option in both the
motor and the generating modes.
8-14 Configurable Control Word CTW
This is an array parameter with 16 elements, 1 element for each
bit in range 0–15. Each of the bits can be configured to any of
the following options.
Option: Function:
This parameter is not valid in software
versions before 4.93.
[0] None The frequency converter ignores the
information in this bit.
[1] Profile The functionality of the bit depends on the
*
default selection in parameter 8-10 Control Word
Profile.
[2] CTW Valid, If set to 1, the frequency converter ignores
active low the remaining bits of the control word.
[3] Safe This function is only available in bits 12–15 of
Option the control word if a safety option is
Reset mounted in the frequency converter. The
