Parameter Descriptions
•
[5]: Power card 6 (rectifier connection in a parallel
frequency converter).
•
[6]: Power card 7 (rectifier connection in a parallel
frequency converter).
•
[7]: Power card 8 (rectifier connection in a parallel
3 3
frequency converter).
43-10 HS Temp. ph.U
Range:
0 °C [-128 -
*
127 °C]
43-11 HS Temp. ph.V
Range:
0 °C [-128 -
*
127 °C]
43-12 HS Temp. ph.W
Range:
0 °C [-128 -
*
127 °C]
43-13 PC Fan A Speed
Range:
0 RPM [0 -
*
65535
RPM]
220
VLT
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the heat sink temperature at the
location of the phase U IGBT power module.
This measurement is not available in all
enclosure sizes. Parameter 16-34 Heatsink Temp.
uses the value in this parameter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the heat sink temperature at the
location of the phase V IGBT power module.
This measurement is not available in all
enclosure sizes. Parameter 16-34 Heatsink Temp.
uses the value in this parameter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the heat sink temperature at the
location of the phase W IGBT power module.
This measurement is not available in all
enclosure sizes. Parameter 16-34 Heatsink Temp.
uses the value in this parameter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the measured speed of fan A on the
power card. Each power card has up to 3 fan
connections. Place the fan in the frequency
converter according to the operating guide. A
typical placement for fan A is in the
backchannel (the external fan).
The value of this parameter is:
Danfoss A/S © 01/2018 All rights reserved.
®
AutomationDrive FC 301/302
43-13 PC Fan A Speed
Range:
43-14 PC Fan B Speed
Range:
0 RPM [0 -
*
65535
RPM]
43-15 PC Fan C Speed
Range:
0 RPM [0 -
*
65535
RPM]
43-20 FPC Fan A Speed
Range:
0 RPM [0 - 65535 RPM] Shows the speed of the power card
*
43-21 FPC Fan B Speed
Range:
0 RPM [0 - 65535 RPM] Shows the speed of the power card
*
Function:
•
The actual fan speed when there is a
DC fan in the frequency converter.
•
Relative speed when there is an AC
fan in the frequency converter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the measured speed of fan B on the
power card. Each power card has up to 3 fan
connections. Place the fan in the frequency
converter according to the operating
instructions. A typical placement for fan B is
on the enclosure door (the internal fan).
The value of this parameter is:
•
The actual fan speed when there is a
DC fan in the frequency converter.
•
Relative speed when there is an AC
fan in the frequency converter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the measured speed of fan C on the
power card. Each power card has up to 3 fan
connections. Place the fan in the frequency
converter according to the operating guide. A
typical placement for fan C is inside the
enclosure (the mixing fan).
The value of this parameter is:
•
The actual fan speed when there is a
DC fan in the frequency converter.
•
Relative speed when there is an AC
fan in the frequency converter.
Function:
fan A.
Function:
fan B.
