Parameter Descriptions
6-60 Terminal X30/8 Output
Option:
[135] Torq.% nom
4-20mA
[136] Power
3 3
4-20mA
[137] Speed
4-20mA
[138] Torque
4-20mA
[139] Bus ctrl.
0-20 mA
[140] Bus ctrl.
4-20 mA
[141] Bus ctrl
0-20mA t.o.
[142] Bus ctrl
4-20mA t.o.
[149] Torque %
lim 4-20mA
[150] Max Out Fr
4-20mA
6-61 Terminal X30/8 Min. Scale
Range:
0 % [0 -
*
200 %]
6-62 Terminal X30/8 Max. Scale
Range:
100.00 [0.00 -
% 200.00 %
*
]
118
Function:
The torque setting is related to the motor
torque setting.
Taken from parameter 1-20 Motor Power [kW].
Taken from parameter 3-03 Maximum
Reference. 20 mA = value in
parameter 3-03 Maximum Reference.
Torque reference related to 160% torque.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency
converter.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency
converter.
Parameter 4-54 Warning Reference Low
defines the behavior of the analog output in
case of bus timeout.
Parameter 4-54 Warning Reference Low
defines the behavior of the analog output in
case of bus timeout.
Torque reference. Parameter 3-00 Reference
Range [Min.-Max.] 0% = 4 mA; 100% = 20
mA.
Parameter 3-00 Reference Range [-Max. -
Max.] -100% = 4 mA; 0% = 12 mA; +100% =
20 mA.
In relation to parameter 4-19 Max Output
Frequency.
Function:
Scales the minimum output of the selected analog
signal on terminal X30/8. Scale the minimum value
as a percentage of the maximum signal value. For
example, enter the value 25% if the output should
be 0 mA at 25% of the maximum output value.
The value can never exceed the corresponding
setting in parameter 6-62 Terminal X30/8 Max. Scale
if the value is below 100%.
This parameter is active when VLT
Purpose I/O MCB 101 is mounted in the frequency
converter.
Function:
Scales the maximum output of the selected
analog signal on terminal X30/8. Scale the
value to the required maximum value of the
current signal output. Scale the output to
give a lower current than 20 mA at full scale
or 20 mA at an output below 100% of the
Danfoss A/S © 01/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
6-62 Terminal X30/8 Max. Scale
Range:
6-63 Terminal X30/8 Bus Control
Range:
0 %
*
6-64 Terminal X30/8 Output Timeout Preset
Range:
0 %
*
100 %]
3.7.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for analog
output 3, terminals X45/1, and X45/2. Analog outputs are
current outputs: 0/4–20 mA. Resolution on analog output
is 11 bit.
6-70 Terminal X45/1 Output
Option:
[0] No operation
[52] MCO 305 0-20
mA
[53] MCO 305 4-20
mA
[100] Output
frequency
®
General
0-20 mA
[101] Reference
0-20 mA
[102] Feedback
[103] Motor current
0-20 mA
Function:
maximum signal value. If 20 mA is the
required output current at a value between
0–100% of the full-scale output, program the
percentage value in the parameter, that is
50%=20 mA. If a current 4–20 mA is
required at maximum output (100%),
calculate the percentage value as follows:
20 mA / desired maximum current x 100 %
20 − 4
i . e . 10 mA : x 100 = 160 %
10
Function:
[0 - 100 %] Holds the level of output X30/8 if controlled
by bus.
Function:
[0 - Holds the preset level of output X30/8.
If there is a fieldbus timeout and a timeout
function is selected in parameter 6-60 Terminal
X30/8 Output, the output is preset to this level.
Function:
Select the function of terminal X45/1 as an
analog current output.
When no signal on the analog output is
present.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min. -
Max.] 0% = 0 mA; 100% = 20 mA.
Parameter 3-00 Reference Range [-Max. -
Max.] -100% = 0 mA; 0% = 10 mA; +100%
= 20 mA.
The value is taken from
parameter 16-37 Inv. Max. Current. The
inverter maximum current (160% current)
is equal to 20 mA.
