Parameter Descriptions
Current
[mA]
20
3 3
0/4
0% Analogue
output Min
Scale
par. 6-71
Illustration 3.46 Output Maximum Scale
6-73 Terminal X45/1 Output Bus Control
Range:
0.00% [0.00 - 100.00%] Holds the level of analog output 3
*
6-74 Terminal X45/1 Output Timeout Preset
Range:
0.00% [0.00 -
*
100.00%]
3.7.9 6-8* Analog Output 4 MCB 113
Parameters for configuring the scaling and limits for analog
output 4, terminals X45/3 and X45/4. Analog outputs are
current outputs: 0/4 to 20 mA. Resolution on analog
output is 11 bit.
6-80 Terminal X45/3 Output
Option:
[0] No operation Same selections available as for
*
6-81 Terminal X45/3 Output Min. Scale
Option:
[0.00%] 0.00 -
*
200.00%
120
®
VLT
Analogue 100% Variable for
Output Max output
Scale example:Speed
par. 6-72 [RPM]
Function:
(terminal X45/1) if controlled by bus.
Function:
Holds the preset level of analog output 3
(terminal X45/1).
If there is a fieldbus timeout and a
timeout function is selected in
parameter 6-70 Terminal X45/1 Output, the
output is preset to this level.
Function:
Select the function of terminal X45/3 as an
analog current output.
parameter 6-70 Terminal X45/1 Output.
Function:
Scales the minimum output of the selected
analog signal on terminal X45/3. Scale the
minimum value as a percentage of the
maximum signal value, for example, 0 mA
(or 0 Hz) is required at 25% of the
maximum output value and 25% is
programmed. The value can never exceed
the corresponding setting in
parameter 6-82 Terminal X45/3 Max. Scale if
the value is below 100%.
Danfoss A/S © 01/2018 All rights reserved.
AutomationDrive FC 301/302
6-81 Terminal X45/3 Output Min. Scale
Option:
6-82 Terminal X45/3 Output Max. Scale
Option:
[0.00%] 0.00 -
*
200.00%
6-83 Terminal X45/3 Output Bus Control
Option:
[0.00%] 0.00 - 100.00% Holds the level of output 4 (X45/3) if
*
6-84 Terminal X45/3 Output Timeout Preset
Option:
[0.00%] 0.00 -
*
100.00%
Function:
This parameter is active when VLT
Extended Relay Card MCB 113 is mounted
in the frequency converter.
Function:
Scales the maximum output of the
selected analog signal on terminal X45/3.
Scale the value to the required maximum
value of the current signal output. Scale
the output to give a lower current than 20
mA at full scale or 20 mA at an output
below 100% of the maximum signal value.
If 20 mA is the required output current at
a value between 0–100% of the full-scale
output, program the percentage value in
the parameter, for example, 50% = 20 mA.
If a current of 4–20 mA is required at
maximum output (100%), calculate the
percentage value as follows (example
where required maximum output is 10
mA):
I mA
RANGE
x 100 %
I mA
DESIRED MAX
20 − 4 mA
= x 100 % = 160 %
10 mA
Function:
controlled by bus.
Function:
Holds the preset level of output 4
(X45/3). If there is a fieldbus timeout and
a timeout function is selected in
parameter 6-80 Terminal X45/3 Output, the
output is preset to this level.
