Parameter Descriptions
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command
given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input
x46/11
[85] Digital input
x46/13
[90] ATEX ETR cur. Available if parameter 1-90 Motor
warning Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 164,
ATEX ETR cur.lim.alarm is active, the
output is 1.
[91] ATEX ETR cur. Available if parameter 1-90 Motor
alarm Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 166,
ATEX ETR freq.lim.alarm is active, the
output is 1.
[92] ATEX ETR freq. Available if parameter 1-90 Motor
warning Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 163,
ATEX ETR cur.lim.warning is active, the
output is 1.
[93] ATEX ETR freq. Available if parameter 1-90 Motor
alarm Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR]. If warning
165, ATEX ETR freq.lim.warning is active,
the output is 1.
[94] RS Flipflop 0 See parameter group 13-1*
Comparators.
[95] RS Flipflop 1 See parameter group 13-1*
Comparators.
[96] RS Flipflop 2 See parameter group 13-1*
Comparators.
[97] RS Flipflop 3 See parameter group 13-1*
Comparators.
[98] RS Flipflop 4 See parameter group 13-1*
Comparators.
MG33MO02
Programming Guide
13-44 Logic Rule Boolean 3
Array [6]
Option:
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
[105] Relay 4
[106] Relay 5
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
[222] Homing Ok
[223] On Target
[224] Position Error
Danfoss A/S © 01/2018 All rights reserved.
Function:
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X47/VLT Extended Relay Card MCB
113.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
NOTICE
This option is available only with
software version 48.20 and
newer.
Homing is completed with the
selected homing function
(parameter 17-80 Homing Function).
NOTICE
This option is available only with
software version 48.20 and
newer.
Positioning is completed and the on-
target signal is sent when the actual
position is within parameter 3-05 On
Reference Window for the duration of
parameter 3-09 On Target Time and the
actual speed does not exceed
parameter 3-05 On Reference Window.
NOTICE
This option is available only with
software version 48.20 and
newer.
The position error exceeds the value
in parameter 4-71 Maximum Position
3 3
