5.2.26 43-** Unit Readouts
Para Parameter description
mete
r
num
ber
43-0* Component Status
43-00 Component Temp.
43-01 Auxiliary Temp.
5 5
43-02 Component SW ID
43-1* Power Card Status
43-10 HS Temp. ph.U
43-11 HS Temp. ph.V
43-12 HS Temp. ph.W
43-13 PC Fan A Speed
43-14 PC Fan B Speed
43-15 PC Fan C Speed
43-2* Fan Pow.Card Status
43-20 FPC Fan A Speed
43-21 FPC Fan B Speed
43-22 FPC Fan C Speed
43-23 FPC Fan D Speed
43-24 FPC Fan E Speed
43-25 FPC Fan F Speed

5.3 Parameter Lists and Options, Software Version 48.20 (IMC)

5.3.1 0-** Operation / Display
Par- Parameter description
ameter #
0-0* Basic Settings
0-01 Language
0-02 Motor Speed Unit
0-03 Regional Settings
0-04 Operating State at Power-up (Hand)
0-09 Performance Monitor
0-1* Set-up Operations
0-10 Active Set-up
0-11 Edit Set-up
0-12 This Set-up Linked to
0-13 Readout: Linked Set-ups
0-14 Readout: Edit Set-ups / Channel
0-15 Readout: actual setup
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-25 My Personal Menu
256
®
VLT AutomationDrive FC 301/302
Default value
0 °C
0 °C
0 N/A
0 °C
0 °C
0 °C
0 RPM
0 RPM
0 RPM
0 RPM
0 RPM
0 RPM
0 RPM
0 RPM
0 RPM
Default value
[0] English
[0] RPM
[0] International
[1] Forced stop, ref=old
0 %
[1] Set-up 1
[1] Set-up 1
[0] Not linked
0 N/A
0 N/A
0 N/A
1617
1614
1610
1613
1602
ExpressionLimit
