Parameter Descriptions
17-34 HIPERFACE Baudrate
Option:
[6] 38400
3.17.3 17-5* Resolver Interface
3 3
This parameter group is used for setting parameters for the
®
VLT Resolver Input MCB 103.
Usually, the resolver feedback is used as motor feedback
from permanent magnet motors with parameter 1-01 Motor
Control Principle set to [3] Flux w/motor feedback.
Resolver parameters cannot be adjusted while the motor is
running.
17-50 Poles
Range:
2 N/A [2 - 2 N/A] Set the pole number on the resolver.
*
17-51 Input Voltage
Range:
7.0 V [2.0 - 8.0
*
V]
17-52 Input Frequency
Range:
10.0 kHz [2.0 - 15.0
*
kHz]
17-53 Transformation Ratio
Range:
0.5 N/A [0.1 - 1.1
*
N/A]
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from
a resolver). Use this function to transfer the speed or position
information from 1 frequency converter to another. To disable
the function, select [0] Disabled.
Option:
[0]
*
[1]
[2]
[3]
194
Function:
Function:
The value is stated in the datasheet for
resolvers.
Function:
Set the input voltage to the resolver. The
voltage is stated as RMS value.
The value is stated in the datasheet for
resolvers.
Function:
Set the input frequency to the
resolver.
The value is stated in the datasheet
for resolvers.
Function:
Set the transformation ratio for the
resolver.
The transformation ratio is:
V
Out
T =
ratio
V
In
The value is stated in the datasheet for
resolvers.
Function:
Disabled
512
1024
2048
Danfoss A/S © 01/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from
a resolver). Use this function to transfer the speed or position
information from 1 frequency converter to another. To disable
the function, select [0] Disabled.
Option:
[4]
17-59 Resolver Interface
Activate the VLT
parameters are selected.
To avoid damage to resolvers, adjust parameter 17-50 Poles and
parameter 17-53 Transformation Ratio before enabling this
parameter.
Option:
[0]
*
[1]
3.17.4 17-6* Monitoring and Application
This parameter group is for selecting extra functions when
®
VLT Encoder Input MCB 102 or VLT
103 is fitted into option slot B as speed feedback.
Monitoring and application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Option:
[0] Clockwise
*
[1] Counter
clockwise
17-61 Feedback Signal Monitoring
Select which action the frequency converter should take if a
faulty encoder signal is detected.
The encoder function in parameter 17-61 Feedback Signal
Monitoring is an electrical check of the hardware circuit in the
encoder system.
Option:
[0]
[1]
*
[2]
[3]
[4]
[5]
[6]
[7]
Function:
4096
®
Resolver Input MCB 103 when the resolver
Function:
Disabled
Enabled
®
Resolver Input MCB
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Change the detected encoder rotation
direction without changing the wiring to
the encoder.
Function:
Disabled
Warning
Trip
Jog
Freeze Output
Max Speed
Switch to Open Loop
Select Setup 1
