Parameter Descriptions
13-52 SL Controller Action
Option:
[127] Deactivate
Touch
3
3
[128] Target Inverse
[129] Target
[130] Act. Speed
Mode
[131] Deact. Speed
Mode
3.13.7 13-9* User-defined Alerts and
Readouts
Parameters in this group allow the configuration of
application-specific messages, warnings, and alarms.
Use the following parameters to configure the frequency
converter to show a message and perform an action when
a specific event occurs:
Parameter 13-90 Alert Trigger – the event that
triggers the user-defined action and message.
Parameter 13-91 Alert Action – the action that the
frequency converter performs when the event
defined in parameter 13-90 Alert Trigger occurs.
Parameter 13-92 Alert Text – the text that the
frequency converter shows in the display when
the event defined in parameter 13-90 Alert Trigger
occurs.
164
®
VLT
AutomationDrive FC 301/302
Function:
NOTICE
This option is available only with
software version 48.20 and newer.
Deactivates the touch probe positioning
mode.
NOTICE
This option is available only with
software version 48.20 and newer.
Changes the sign of the active target
position value.
NOTICE
This option is available only with
software version 48.20 and newer.
The active target position is not changed.
NOTICE
This option is available only with
software version 48.20 and newer.
Activates the speed mode when option
[9] Positioning or option [10] Synchroni-
zationis selected in
parameter 1-00 Configuration Mode.
NOTICE
This option is available only with
software version 48.20 and newer.
Deactivates the speed mode and activates
the option selected in
parameter 1-00 Configuration Mode.
Danfoss A/S © 01/2018 All rights reserved.
For example, consider the following use case:
If there is an active signal on digital input 32, the
frequency converter shows the message Valve 5 open in
the display and ramps down to a stop.
To achieve this configuration, make the following settings:
Parameter 13-90 Alert Trigger = [37] Digital input
DI32.
Parameter 13-91 Alert Action = [5] Stop & warning.
Parameter 13-92 Alert Text = Valve 5 open.
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option:
[0]
False
*
[1]
True
[18]
Reversing
[22]
Comparator 0
[23]
Comparator 1
[24]
Comparator 2
[25]
Comparator 3
[26]
Logic rule 0
[27]
Logic rule 1
[28]
Logic rule 2
[29]
Logic rule 3
[30]
SL Time-out 0
[31]
SL Time-out 1
[32]
SL Time-out 2
[33]
Digital input DI18
[34]
Digital input DI19
[35]
Digital input DI27
[36]
Digital input DI29
[37]
Digital input DI32
[38]
Digital input DI33
[50]
Comparator 4
[51]
Comparator 5
[60]
Logic rule 4
[61]
Logic rule 5
[70]
SL Time-out 3
[71]
SL Time-out 4
[72]
SL Time-out 5
[73]
SL Time-out 6
[74]
SL Time-out 7
[90]
ECB Drive Mode
[91]
ECB Bypass Mode
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter 13-90 Alert Trigger occurs.
Option:
[0]
Info
*
[1]
Warning
[2]
Freeze output
Function:
Function:
MG33MO02
