Parameter Descriptions
[2] Drive ready
3 3
[3] Drive ready/
remote control
[4] Enable/no
warning
[5] VLT running
[6] Running/no
warning
[7] Run in
range/no
warning
[8] Run on
reference/no
warning
[9] Alarm
[10] Alarm or
warning
[11] At torque limit
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[15] Out of range
[16] Below speed,
low
[17] Above speed,
high
[18] Out of
feedback range
[19] Below feedback
low
[20] Above
feedback high
[21] Thermal
warning
96
®
VLT AutomationDrive FC 301/302
controlled by a 24 V external supply
®
(VLT 24 V DC Supply MCB 107) and the
main power to the unit is not detected.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in auto-on mode.
Ready for operation. No start or stop
command has been given (start/disable).
No warnings are active.
The motor runs and shaft torque is
present.
The output speed is higher than the
speed set in parameter 1-81 Min Speed for
Function at Stop [RPM]. The motor runs
and there are no warnings.
Motor runs within the programmed
current and speed ranges set in
parameter 4-50 Warning Current Low to
parameter 4-53 Warning Speed High. There
are no warnings.
Motor runs at reference speed. No
warnings.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The torque limit set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit Generator
Mode has been exceeded.
The motor current is outside the range
set in parameter 4-18 Current Limit.
Motor current is lower than set in
parameter 4-50 Warning Current Low.
Motor current is higher than set in
parameter 4-51 Warning Current High.
Output frequency is outside the
frequency range set in
parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
Output speed is lower than the setting in
parameter 4-52 Warning Speed Low.
Output speed is higher than the setting
in parameter 4-53 Warning Speed High.
Feedback is outside the range set in
parameter 4-56 Warning Feedback Low and
parameter 4-57 Warning Feedback High.
Feedback is below the limit set in
parameter 4-56 Warning Feedback Low.
Feedback is above the limit set in
parameter 4-57 Warning Feedback High.
The thermal warning turns on when the
temperature exceeds the limit in the
Danfoss A/S © 01/2018 All rights reserved.
motor, the frequency converter, the brake
resistor, or the thermistor.
[22] Ready, no Frequency converter is ready for
thermal operation, and there is no overtem-
warning perature warning.
[23] Remote, ready, Frequency converter is ready for
no thermal operation and is in auto-on mode. There
warning is no overtemperature warning.
[24] Ready, no over/ Frequency converter is ready for
undervoltage operation and the mains voltage is within
the specified voltage range (see the
section General Specifications in the
frequency converter design guide).
[25] Reverse The motor runs (or is ready to run)
clockwise when logic = 0 and counter-
clockwise when logic = 1. The output
changes when the reversing signal is
applied.
[26] Bus OK Active communication (no timeout) via
the serial communication port.
[27] Torque limit Use in performing a coast stop and in
and stop torque limit condition. If the frequency
converter has received a stop signal and
is at the torque limit, the signal is logic 0.
[28] Brake, no brake Brake is active and there are no warnings.
warning
[29] Brake ready, no Brake is ready for operation and there are
fault no faults.
[30] Brake fault Output is logic 1 when the brake IGBT is
(IGBT) short-circuited. Use this function to
protect the frequency converter if there is
a fault on the brake modules. To cut out
the main voltage from the frequency
converter, use the output/relay.
[31] Relay 123 Relay is activated when [0] Control word is
selected in parameter group 8-**
Communications and Options.
[32] Mechanical Enables control of an external mechanical
brake control brake. For more information on
mechanical brake control, refer to the
frequency converter design guide.
[33] Safe stop Indicates that the Safe Torque Off on
activated (FC terminal 37 is activated.
302 only)
[35] External
Interlock
[40] Out of ref Active when the actual speed is outside
range settings in parameter 4-52 Warning Speed
Low to parameter 4-55 Warning Reference
High.
[41] Below Active when actual speed is below speed
reference low reference setting.
[42] Above Active when actual speed is above speed
reference high reference setting.
[43] Extended PID
Limit
