Danfoss VLT AutomationDrive FC 301 Programming Manual page 278

Parameter Lists
5.3.18 18-** Data Readouts 2
Par- Parameter description
ameter #
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA]
18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-5* Active Alarms/Warnings
5 5
18-55 Active Alarm Numbers
18-56 Active Warning Numbers
18-6* Inputs & Outputs 2
18-60 Digital Input 2
5.3.19 30-** Special Features
Par- Parameter description
ameter #
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]
Locked Rotor Detection Speed Error
30-24 [%]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
5.3.20 35-** Sensor Input Option
Par- Parameter description
ameter #
35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit
35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temperature Unit
35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temperature Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7
35-24 Term. X48/7 Filter Time Constant
276
®
VLT AutomationDrive FC 301/302
Default value
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
Default value
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
25 %
ExpressionLimit
ExpressionLimit
0.015 N/A
0.100 N/A
Default value
[60] °C
[0] Not Connected
[60] °C
[0] Not Connected
[60] °C
[0] Not Connected
[5] Stop and trip
0.001 s
[0] Disabled
ExpressionLimit
ExpressionLimit
0.001 s
Danfoss A/S © 01/2018 All rights reserved.
4 set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
4 set-up FC 302 Change
only during
operation
All set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x FALSE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
4 set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conversi Type
on index
-3 Int32
0 Int16
0 Int16
0 Int16
0 Uint16
0 Uint16
0 Uint16
Conversi Type
on index
-2 Uint16
-1 Uint32
- Uint8
-2 Uint8
-1 Uint32
-6 Int32
-2 Uint32
-4 Uint32
-3 Uint16
Conversi Type
on index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
MG33MO02
