Parameter Descriptions
NOTICE
Options [4] PTC 1 Alarm to [9] PTC 1 & Relay W/A are only
available when the MCB 112 is connected.
NOTICE
Selecting Auto Reset/Warning enables automatic restart
of the frequency converter.
Function Num PTC
ber
No Function [0] –
Safe Torque Off [1]* –
Alarm
Safe Torque Off [3] –
Warning
PTC 1 Alarm [4] PTC 1 Safe Torque
Off [A71]
PTC 1 Warning [5] PTC 1 Safe Torque
Off [W71]
PTC 1 & Relay A [6] PTC 1 Safe Torque
Off [A71]
PTC 1 & Relay W [7] PTC 1 Safe Torque
Off [W71]
PTC 1 & Relay A/W [8] PTC 1 Safe Torque
Off [A71]
PTC 1 & Relay W/A [9] PTC 1 Safe Torque
Off [W71]
Table 3.19 Overview of Functions, Alarms, and Warnings
W means warning and A means alarm. For further information, see
Alarms and Warnings in chapter 6 Troubleshooting.
A dangerous failure related to Safe Torque Off issues alarm
72, Dangerous failure.
Refer to Table 6.1.
5-20 Terminal X46/1 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
5-21 Terminal X46/3 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
MG33MO02
Programming Guide
5-22 Terminal X46/5 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-23 Terminal X46/7 Digital Input
Option:
Relay
[0] No operation This parameter is active when option module
*
–
Safe Torque Off
[A68]
Safe Torque Off
[W68]
5-24 Terminal X46/9 Digital Input
–
Option:
[0] No operation This parameter is active when option module
*
–
Safe Torque Off
[A68]
Safe Torque Off
[W68]
5-25 Terminal X46/11 Digital Input
Safe Torque Off
Option:
[W68]
[0] No operation This parameter is active when option module
*
Safe Torque Off
[A68]
5-26 Terminal X46/13 Digital Input
Option:
[0] No operation This parameter is active when option module
*
3.6.3 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
parameter 5-01 Terminal 27 Mode, and set the I/O function
for terminal 29 in parameter 5-02 Terminal 29 Mode.
NOTICE
These parameters cannot be adjusted while the motor is
running.
[0] No operation
[1] Control ready
Danfoss A/S © 01/2018 All rights reserved.
Function:
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
Function:
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
Function:
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
Function:
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
Function:
®
VLT Extended Relay Card MCB 113 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
Default for all digital outputs and relay
outputs.
The control card is ready, for example:
Feedback from a frequency converter
3 3
