Parameter Lists
30-5* Unit Configuration
30-50 Heat Sink Fan Mode
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
30-9* Wifi LCP
30-90 SSID
30-91 Channel
5 5
30-92 Password
30-93 Security type
30-94 IP address
30-95 Submask
30-96 Port
30-97 Wifi Timeout Action
5.2.20 32-** MCO Basic Settings
Para Parameter description
mete
r
num
ber
32-0* Encoder 2
32-00 Incremental Signal Type
32-01 Incremental Resolution
32-02 Absolute Protocol
32-03 Absolute Resolution
32-04 Absolute Encoder Baudrate X55
32-05 Absolute Encoder Data Length
32-06 Absolute Encoder Clock Frequency
32-07 Absolute Encoder Clock Generation
32-08 Absolute Encoder Cable Length
32-09 Encoder Monitoring
32-10 Rotational Direction
32-11 User Unit Denominator
32-12 User Unit Numerator
32-13 Enc.2 Control
32-14 Enc.2 node ID
32-15 Enc.2 CAN guard
32-3* Encoder 1
32-30 Incremental Signal Type
32-31 Incremental Resolution
32-32 Absolute Protocol
32-33 Absolute Resolution
32-35 Absolute Encoder Data Length
32-36 Absolute Encoder Clock Frequency
32-37 Absolute Encoder Clock Generation
32-38 Absolute Encoder Cable Length
250
®
VLT AutomationDrive FC 301/302
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
5 N/A
ExpressionLimit
[2] WPA_WPA2
ExpressionLimit
ExpressionLimit
5001 N/A
[0] Do Nothing
Default value
[1] RS422 (5V TTL)
1024 N/A
[0] None
8192 N/A
[4] 9600
25 N/A
262 kHz
[1] On
0 m
[0] Off
[1] No action
1 N/A
1 N/A
[0] No soft changing
127 N/A
[0] Off
[1] RS422 (5V TTL)
1024 N/A
[0] None
8192 N/A
25 N/A
262 kHz
[1] On
0 m
