Danfoss VLT AutomationDrive FC 301 Programming Manual page 72

Parameter Descriptions
3-16 Reference Resource 2
Option:
[8] Frequency input
33
[11] Local bus
3 3
reference
[20] Digital pot.meter
*
[21] Analog input
X30-11
[22] Analog input
X30-12
3-17 Reference Resource 3
Option:
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus
*
reference
[20] Digital pot.meter
[21] Analog input
X30-11
[22] Analog input
X30-12
3-18 Relative Scaling Reference Resource
Option:
70
®
VLT AutomationDrive FC 301/302
Function:
Reference from terminals 68 and 69.
Function:
Select the reference input to be used
rd
for the 3 reference signal.
Parameter 3-15 Reference Resource 1,
parameter 3-16 Reference Resource 2,
and parameter 3-17 Reference Resource
3 define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
Reference from terminals 68 and 69.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select a variable value to be added to
the fixed value (defined in
parameter 3-14 Preset Relative Reference).
The sum of the fixed and variable values
(labeled Y in Illustration 3.24) is
multiplied by the actual reference
(labeled X in Illustration 3.24). This
product is then added to the actual
reference (X+X*Y/100) to give the
resulting actual reference.
Danfoss A/S © 01/2018 All rights reserved.
3-18 Relative Scaling Reference Resource
Option: Function:
Y
X
Illustration 3.24 Resulting Actual
Reference
[0] No function
*
[1] Analog input 53
[2] Analog input 54
[7] Frequency input
29
[8] Frequency input
33
[11] Local bus Reference from terminals 68 and 69.
reference
[20] Digital pot.meter
[21] Analog input
X30-11
[22] Analog input
X30-12
3-19 Jog Speed [RPM]
Range: Function:
150. [0 - par. Enter a value for the jog speed n
RPM 4-13 a fixed output speed. The frequency
*
RPM] converter runs at this speed when the jog
function is activated. The maximum limit is
defined in parameter 4-13 Motor Speed High
Limit [RPM].
See also parameter 3-80 Jog Ramp Time.
3.4.3 3-2* References II
3-20 Preset Target
Range:
0 CustomRea- [-2147483648 -
doutUnit2 2147483647
*
CustomRea-
doutUnit2]
Resulting
Relative Z
actual
Z=X+X*Y/100
reference
, which is
JOG
Function:
NOTICE
This parameter is only
available with software
version 48.XX.
Array [8]
Set up to 8 target positions.
Select from the 8 preset
positions using digital inputs
or the fieldbus control word.
MG33MO02
