Parameter Descriptions
13-10 Comparator Operand
Option:
[180] Local referecnce
active
3 3
[181] Remote
reference active
[182] Start command
[183] Drive stopped
[185] Drive in hand
mode
[186] Drive in auto
mode
[187] Start command
given
[190] Digital input
x30/2
[191] Digital input
x30/3
[192] Digital input
x30/4
[193] Digital input
x46/1
[194] Digital input
x46/3
[195] Digital input
x46/5
[196] Digital input
x46/7
[197] Digital input
x46/9
[198] Digital input
x46/11
[199] Digital input
x46/13
[222] Homing Ok
[223] On Target
148
®
VLT AutomationDrive FC 301/302
Function:
Active when parameter 3-13 Reference Site
is [2] Local or when
parameter 3-13 Reference Site is [0] Linked
to hand/auto, at the same time as the
LCP is in hand-on mode.
Active when parameter 3-13 Reference Site
is [1] Remote or [0] Linked to hand/auto,
while the LCP is in auto-on mode.
Active when there is an active start
command and no stop command.
A stop command (jog, stop, qstop, coast)
is issued – and not from the SLC itself.
Active when the frequency converter is
in hand-on mode.
Active when the frequency converter is
in auto-on mode.
NOTICE
This option is available only with
software version 48.20 and newer.
Homing is completed with the selected
homing function
(parameter 17-80 Homing Function).
NOTICE
This option is available only with
software version 48.20 and newer.
Danfoss A/S © 01/2018 All rights reserved.
13-10 Comparator Operand
Option: Function:
Positioning is completed and the on
target signal is sent when the actual
position is within parameter 3-05 On
Reference Window for the duration of
parameter 3-09 On Target Time and the
actual speed does not exceed
parameter 3-05 On Reference Window.
NOTICE
[224] Position Error
This option is available only with
software version 48.20 and newer.
The position error exceeds the value in
parameter 4-71 Maximum Position Error for
the time set in parameter 4-72 Position
Error Timeout.
NOTICE
[225] Position Limit
This option is available only with
software version 48.20 and newer.
The position is outside the limits set in
parameter 3-06 Minimum Position and
parameter 3-07 Maximum Position.
NOTICE
[226] Touch on
Target
This option is available only with
software version 48.20 and newer.
Target position is reached in touch probe
position mode.
NOTICE
[227] Touch Activated
This option is available only with
software version 48.20 and newer.
Touch probe positioning active. The
frequency converter monitors the touch
probe sensor input.
13-11 Comparator Operator
Option: Function:
Select the operator to be used in the
comparison. This is an array parameter
containing comparator operators 0–5.
[0] < The result of the evaluation is true when the
variable selected in parameter 13-10 Comparator
Operand is smaller than the fixed value in
parameter 13-12 Comparator Value. The result is
false if the variable selected in
parameter 13-10 Comparator Operand is greater
than the fixed value in
parameter 13-12 Comparator Value.
