Danfoss VLT AutomationDrive FC 301 Programming Manual page 250

Parameter Lists
5.2.17 17-** Position Feedback
Para Parameter description
mete
r
num
ber
17-1* Inc. Enc. Interface
17-10 Signal Type
17-11 Resolution (PPR)
17-2* Abs. Enc. Interface
5 5
17-20 Protocol Selection
17-21 Resolution (Positions/Rev)
17-22 Multiturn Revolutions
17-24 SSI Data Length
17-25 Clock Rate
17-26 SSI Data Format
17-34 HIPERFACE Baudrate
17-5* Resolver Interface
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
17-6* Monitoring and App.
17-60 Feedback Direction
17-61 Feedback Signal Monitoring
17-7* Position Scaling
17-70 Position Unit
17-71 Position Unit Scale
17-72 Position Unit Numerator
17-73 Position Unit Denominator
17-74 Position Offset
5.2.18 18-** Data Readouts 2
Para Parameter description
mete
r
num
ber
18-0* Maintenance Log
18-00 Maintenance Log: Item
18-01 Maintenance Log: Action
18-02 Maintenance Log: Time
18-03 Maintenance Log: Date and Time
18-2* Motor Readouts
18-27 Safe Opt. Est. Speed
18-28 Safe Opt. Meas. Speed
18-29 Safe Opt. Speed Error
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA]
248
®
VLT AutomationDrive FC 301/302
Default value
[1] RS422 (5V TTL)
1024 N/A
[0] None
ExpressionLimit
1 N/A
13 N/A
260 kHz
[0] Gray code
[4] 9600
2 N/A
7 V
10 kHz
0.5 N/A
[0] Disabled
[0] Disabled
[0] Clockwise
[1] Warning
[0] pu
0 N/A
1024 N/A
1 N/A
0 N/A
Default value
0 N/A
0 N/A
0 s
ExpressionLimit
0 RPM
0 RPM
0 RPM
0 N/A
Danfoss A/S © 01/2018 All rights reserved.
4 set-up FC 302 only Change
during
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
2 set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
4 set-up FC 302 only Change
during
operation
All set-ups x FALSE
All set-ups x FALSE
All set-ups x FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conversio Type
n index
- Uint8
0 Uint16
- Uint8
0 Uint32
0 Uint32
0 Uint8
3 Uint16
- Uint8
- Uint8
0 Uint8
-1 Uint8
2 Uint8
-1 Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int8
0 Int32
0 Int32
0 Int32
Conversio Type
n index
0 Uint8
0 Uint8
0 Uint32
TimeO
0 fDay
67 Int32
67 Int32
67 Int32
-3 Int32
MG33MO02
