Parameter Descriptions
parameter 17-90 Absolute Position Mode and
parameter 17-91 Relative Position Mode.
Synchronization mode: High signal locks the
actual follower position to the actual master
position. The follower starts and catches up
with the master. Low signal stops the
synchronization and the follower makes a
controlled stop.
NOTICE
[114] Sync. to
Pos. Mode
This option is available only with
software version 48.XX.
Select positioning in synchronization mode.
NOTICE
[115] Home
Sensor
This option is available only with
software version 48.XX.
Normally open contact for defining the
home position. The function is defined in
parameter 17-80 Homing Function. Available
only at digital inputs 18, 32, and 33.
NOTICE
[116] Home
Sensor Inv.
This option is available only with
software version 48.XX.
Normally closed contact for defining the
home position. The function is defined in
parameter 17-80 Homing Function. Available
only at digital inputs 18, 32, and 33.
NOTICE
[117] Touch
Sensor
This option is available only with
software version 48.XX.
Normally open contact. Serves as a reference
for touch probe positioning. Available only at
digital inputs 18, 32, and 33.
NOTICE
[118] Touch
Sensor
This option is available only with
software version 48.XX.
Normally closed contact. Serves as a
reference for touch probe positioning.
Available only at digital inputs 18, 32, and
33.
NOTICE
[119] Speed
mode
This option is available only with
software version 48.XX.
Select the speed mode when [9] Positioning
or [10] Synchronization is selected in
parameter 1-00 Configuration Mode. Speed
reference is set by reference resource 1 or
fieldbus REF1 relative to
parameter 3-03 Maximum Reference.
[231] Power Limit Select this option to activate the power limit
Mot. function in the motor mode. See parameter
group 4-8* Power Limit.
[232] Power Limit Select this option to activate the power limit
Gen. function in the generating mode. See
parameter group 4-8* Power Limit.
MG33MO02
Programming Guide
[233] Power Limit
Both
5-10 Terminal 18 Digital Input
Option:
[8] Start Functions are described in parameter group 5-1*
*
5-11 Terminal 19 Digital Input
Option:
[10] Reversing Functions are described in parameter group 5-1*
*
5–12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described in parameter group
*
5–13 Terminal 29 Digital Input
Option:
[14] Jog Functions are described in parameter group 5-1*
*
5-14 Terminal 32 Digital Input
Option:
No operation Functions are described in parameter group 5-1*
5-15 Terminal 33 Digital Input
Option:
[0] No operation Functions are described in parameter group
*
5-16 Terminal X30/2 Digital Input
Option:
[0] No operation This parameter is active when option module
*
Danfoss A/S © 01/2018 All rights reserved.
Select this option to activate the power limit
function in both the motor and the
generating mode. See parameter group 4-8*
Power Limit.
Function:
Digital Inputs.
Function:
Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
NOTICE
This parameter is available for FC 302 only.
Select the function from the available digital input
range and the additional options [60] Counter A, [61]
Counter A, [63] Counter B, and [64] Counter B. Counters
are used in smart logic control functions.
Digital Inputs.
Function:
Select the function from the available digital
input range.
Digital Inputs.
Function:
Select the function from the available digital
input range and the additional options [60]
Counter A, [61] Counter A, [63] Counter B and
[64] Counter B. Counters are used in smart
logic control functions.
5-1* Digital Inputs.
Function:
®
VLT General Purpose I/O MCB 101 is
installed in the frequency converter.
Functions are described in parameter group
5-1* Digital Inputs.
