Troubleshooting
Number Description
73 Safe Stop Auto Restart
74 PTC Thermistor
75 Illegal Profile Sel.
76 Power unit setup
77 Reduced power mode
78 Tracking error
79 Illegal PS config
80 Frequency converter Initialized to default value
81 CSIV corrupt
82 CSIV parameter error
83 Illegal option combination
6 6
84 No safety option
88 Option detection
89 Mechanical brake sliding
90 Feedback monitor
91 Analog input 54 wrong settings
99 Locked rotor
101 Speed monitor
104 Mixing fans
122 Mot. rotat. unexp.
123 Motor mod. changed
157 Power Limit Mot.
158 Power Limit Gen.
163 ATEX ETR cur.lim.warning
164 ATEX ETR cur.lim.alarm
165 ATEX ETR freq.lim.warning
166 ATEX ETR freq.lim.alarm
210 Position tracking
211 Position limit
212 Homing not done
213 Homing timeout
214 No sensor input
215 Start fwd/rev
216 Touch timeout
220 Configuration File Version not supported
246 Pwr.card supply
250 New spare part
251 New type code
430 PWM Disabled
Table 6.1 Alarm/Warning Code List
(X) Dependent on parameter.
1) Cannot be auto reset via parameter 14-20 Reset Mode.
280
®
VLT AutomationDrive FC 301/302
Warning Alarm/
trip
(X) (X)
– –
– X
X –
X –
(X) (X)
– X
– X
– X
– X
– –
– X
– –
X –
(X) (X)
– –
– X
X X
X X
– X
– X
– X
– X
X –
– X
X –
– X
X X
X X
– X
– X
– X
X X
– X
X –
– –
– –
– X
– X
Danfoss A/S © 01/2018 All rights reserved.
Alarm/ Parameter
trip lock reference
– Parameter 5-19 Terminal 37 Safe Stop
X –
– –
– –
– Parameter 14-59 Actual Number of Inverter
Units
– Parameter 4-34 Tracking Error Function
X –
– –
– –
– –
X –
– –
X –
– –
– Parameter 17-61 Feedback Signal Monitoring
X S202
X –
– –
– –
– –
– –
– Parameter 4-80 Power Limit Func. Motor
Mode, parameter 4-82 Power Limit Motor
Mode
– Parameter 4-81 Power Limit Func. Generator
Mode, parameter 4-83 Power Limit Generator
Mode
– –
– –
– –
– –
– Parameter 4-70 Position Error Function,
parameter 4-71 Maximum Position Error,
parameter 4-72 Position Error Timeout
– Parameter 3-06 Minimum Position,
parameter 3-07 Maximum Position,
parameter 4-73 Position Limit Function
– Parameter 17-80 Homing Function
– Parameter 17-85 Homing Timout
– –
– Parameter 4-74 Start Fwd/Rev Function
– Parameter 4-75 Touch Timout
– –
X –
X –
X –
– –
